Integrated solar street light. Panel + battery + LED in one housing, 13-year battery life.
Everything, on one pole.
The all-in-one architecture brings panel, battery, controller and luminaire into a single housing — a complete solar streetlight that lands on a pole in under an hour. Built for municipalities and society rollouts where deployment speed and zero-trench economics matter more than custom optic angles. Lumileds 3030 2D engines, LiFePO4 battery rated for thirteen years, IoT-ready by option. The pole is the entire bill of materials.
The headline figures that put Integron All-in-One on tendered municipal projects.
- 13-yr Battery life
- 5000+ Charge cycles
- 200 lm/W LED efficacy
- 15K lm Peak output
The completespecification.
01Electrical
- Wattage package
- 40–60 W · 60–80 W · 80–100 W · 100–120 W
- Charge controller
- Intelligent solar charge controller
- Controller type
- MPPT
- Voltage range
- Light 36V / 48V · Battery 12V / 24V · PV 17–48V / 34–48V
- Lumen package
- >6,000 · >9,000 · >12,000 · >15,000 lm
- Lumen range
- 4,550 – 42,990 lm available
02Light
- System efficacy
- 140 – 150 lm/W
- Light source
- Lumileds 3030 2D / TYF 3030
- LED efficiency
- Up to 200 lm/W
- Drive current
- Below 50% of LED max forward current
- CRI
- ≥ 70
- Beam angle
- Type II M 90° × 150° (other types available)
- CCT
- CW 5700K · NW 4000K · WW 3000K ±500K
- Lifetime
- 50,000 hrs (L70 @ Ta = 35°C)
03Battery
- Capacity
- >230 · >320 · >576 · >768 Wh
- Type
- Lithium Iron Phosphate (LiFePO4)
- Cycles / life
- >4,000 cycles (up to 5,000) · up to 13 years
04Solar PV
- Panel wattage
- >50 · >60 · >80 · >105 W
- PV type
- Monocrystalline · Mono PERC
- Panel life
- > 10 years
05Environmental
- Mounting
- 48 – 60 mm pole, side entry
- Mounting height
- 6 – 8 m / 8 – 12 m
- Working temp.
- Light −40 °C to 55 °C · Battery 0 °C to 45 °C · Panel −40 °C to 85 °C
- Humidity
- Up to 95% RH
06Mechanical
- Housing
- High pressure die-cast aluminium
- Battery console
- Aluminium alloy
- Gasket
- Heat-resistant silicone rubber
- Front cover
- Tempered glass
- Finish
- Corrosion-resistant powder coating
Lift the poleand the system arrives with it.
- Battery
- LiFePO4 · 13 yrs
- Cycles
- > 4,000
- LED
- Lumileds 3030 2D
- Efficacy
- 150 lm/W
- Autonomy
- 3 – 5 nights
- Ingress
- IP65
Integron All-in-One in the field
- 01
Society streets
Whole housing schemes lit without a trench.
- 02
Parks & pathways
Soft light over lawns, benches and slow walks.
- 03
Off-grid villages
A pole, a panel, a battery — and a lit street.
- 04
Government rollouts
Tendered programs that have to install fast.
40120W
The range of Integron All-in-One, by application.
- 0140 – 60 W
Pathways, parks, society interiors
- 0260 – 80 W
Residential streets, society arterials
- 0380 – 100 W
Secondary roads, society perimeters
- 04100 – 120 W
Major society streets, off-grid villages
